Adet bazlı fiyat
- 1+ adet$3.19
- 10+ adet$3.01
- 100+ adet$2.84
- 500+ adet$2.68
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Insulation Resistance
- 1GOhm
- Contact Materials
- Brass
- Sıra Sayısı
- 2
- Özellikler
- Pick and Place, Solder Retention
- Contact Finish Mating
- Gold
- Connector Type
- Header
- Material Flammability Rating
- UL94 V-0
- REACH Uyumluluk Kodu
- unknown
- Contact Gender
- Male
- Row Spacing Mating
- 0.079 (2.00mm)
- Option
- GENERAL PURPOSE
- Fastening Type
- Detent Lock
- Contact Finish Thickness Mating
- 8.00μin 0.203μm
- Pcb Contact Pattern
- RECTANGULAR
- Parça Durumu
- Active
- Withdrawl Forcemin
- .3058 N
- RoHS Durumu
- RoHS Compliant
- Seri
- DF11
- Insulation Height
- 0.283 7.19mm
- Housing Material
- Polyamide
- Montaj
- Surface Mount
- Shrouding
- Shrouded - 4 Wall
- Flammability Rating
- UL94 V-0
- JESD-609 Kodu
- e3
- Pitch Mating
- 0.079 2.00mm
- Dielectric Withstanding Voltage
- 650VAC V
- Ul Flammability Code
- 94V-0
- Number Of Conductors
- ONE
- Reliability
- COMMERCIAL
- Rated Current Signal
- 2A
- Kurşunsuz Kodu
- yes
- Contact Resistance
- 30mOhm
- Contact Shape
- Circular
- Çalışma Sıcaklığı
- -30°C~85°C
- Renk
- Beige, Black
- Fabrika Tedarik Süresi
- 10 Weeks
- Polarization Key
- GUIDE SLOT(S)
- Din Conformance
- NO
- Mixed Contacts
- NO
- Ambalaj
- Tape & Reel (TR)
