DF11-6DEP-2C

Teknik Özellikler

Insulation Resistance

1000000000Ohm

Max Voltage Rating Ac

250V

Gender

Female

Sıra Sayısı

2

Maks. Çalışma Sıcaklığı

85°C

Min. Çalışma Sıcaklığı

-30°C

Connector Type

Plug

Parça Durumu

Active

Option

WITH CABLE ASSEMBLY

Seri

DF11

Lead Pitch

2mm

RoHS Durumu

RoHS Compliant

Housing Material

Polyamide

Radyasyon Dayanımı

No

Withdrawl Forcemin

.3058 N

Wire Gauge Min

26 AWG

Wire Size Min

30 AWG

Pitch

0.079 2.00mm

Montaj

Panel, Snap in

Note

Contacts Not Included

Contact Design

PREASSEM CONN

Rated Current Signal

2A

Reliability

COMMERCIAL

Additional Feature

PANEL MOUNTABLE

Contact Resistance

30mOhm

Kurşunsuz Kodu

yes

Row Spacing

0.079 (2.00mm)

Uzunluk

13mm

Kurşunsuz

Lead Free

Orientation

Straight

Renk

Black

Fabrika Tedarik Süresi

12 Weeks

Polarization Key

POLARIZED HOUSING

Din Conformance

NO

Ambalaj

Bulk

Mixed Contacts

NO

Nominal Gerilim

250V

ECCN Kodu

EAR99

Wire Gauge Max

22 AWG

Contact Termination

Crimp
