Adet bazlı fiyat
- 1+ adet$0.19
- 10+ adet$0.18
- 100+ adet$0.17
- 500+ adet$0.16
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Mil Conformance
- NO
- Rated Current Signal
- 2A
- Durability
- 30 Cycles
- Mixed Contacts
- NO
- Pozisyon Sayısı
- 32
- Ambalaj
- Bulk
- Fabrika Tedarik Süresi
- 10 Weeks
- Contact Termination
- Crimp
- Contact Finish Mating
- TIN
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Parça Durumu
- Active
- Wire Size Min
- 30 AWG
- Orientation
- Straight
- Contact Plating
- Tin
- Mounting Option1
- LOCKING MECH
- Ul Flammability Code
- 94V-0
- Operating Temperature Min
- -30°C
- Reliability
- COMMERCIAL
- Montaj Tipi
- Free Hanging (In-Line)
- Connector Type
- Receptacle
- Insulation Resistance
- 1GOhm
- Option
- GENERAL PURPOSE
- Kurşunsuz Kodu
- yes
- Din Conformance
- NO
- Body Length Or Diameter
- 1.339 inch
- Pitch
- 0.079 2.00mm
- Housing Material
- Plastic
- HTS Kodu
- 8536.69.40.40
- ECCN Kodu
- EAR99
- Contact Resistance
- 30mOhm
- RoHS Durumu
- RoHS Compliant
- Lead Pitch
- 2mm
- Reference Standard
- UL, CSA
- Contact Type
- Female Socket
- Note
- Contacts Not Included
- Yayın Yılı
- 2008
- Polarization Key
- POLARIZED RIB(S)
- Contact Materials
- PHOSPHOR BRONZE
- Total Number Of Contacts
- 32
- Filter Feature
- NO
