Adet bazlı fiyat
- 1+ adet$1.06
- 10+ adet$1.00
- 100+ adet$0.94
- 500+ adet$0.89
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Contact Length Post
- 0.118 3.00mm
- Contact Lengthmating
- 0.118 3.00mm
- Genişlik
- 5mm
- RoHS Durumu
- RoHS Compliant
- Material Flammability Rating
- UL94 V-0
- Lead Pitch
- 2mm
- Row Spacing Mating
- 0.079 (2.00mm)
- HTS Kodu
- 8536.69.40.40
- Contact Shape
- Square
- Stack Height Mating
- 7.55 7.8mm 8.9mm
- ECCN Kodu
- EAR99
- Contact Resistance
- 30mOhm
- Pitch Mating
- 0.079 2.00mm
- Yayın Yılı
- 2010
- Overall Contact Length
- 0.299 7.60mm
- Pcb Contact Pattern
- RECTANGULAR
- Polarization Key
- GUIDE SLOT(S)
- Terminal
- Solder
- Contact Materials
- Brass
- Reference Standard
- UL, CSA
- Contact Type
- Male Pin
- Withdrawl Forcemin
- .3058 N
- Kurşunsuz
- Lead Free
- Iec Conformance
- NO
- Number Of Conductors
- ONE
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- JESD-609 Kodu
- e4
- Filter Feature
- NO
- Yükseklik
- 6.6mm
- Akım Değeri
- 2A
- Fastening Type
- Detent Lock
- Max Current Rating
- 2A
- Seri
- DF11
- Number Of Pcb Rows
- 2
- Body Breadth
- 0.197 inch
- Dielectric Withstanding Voltage
- 650VAC V
- Additional Feature
- 100 PCS. PER BAG PACKAGING
- Nominal Gerilim
- 250V
- Contact Finish Thickness Mating
- 8.00μin 0.203μm
- Sıra Sayısı
- 2
