Adet bazlı fiyat
- 1+ adet$0.12
- 10+ adet$0.11
- 100+ adet$0.11
- 500+ adet$0.10
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Mixed Contacts
- NO
- Operating Temperature Max
- 85°C
- Orientation
- Straight
- Gender
- Female
- Seri
- A4
- Contact Termination
- Crimp
- Kurşunsuz
- Lead Free
- Montaj Tipi
- Free Hanging (In-Line)
- Reference Standard
- UL
- Option
- GENERAL PURPOSE
- Iec Conformance
- NO
- Montaj
- Cable, Free Hanging
- Renk
- Black
- Total Number Of Contacts
- 12
- Ambalaj
- Bulk
- Wire Size Max
- 26 AWG
- Pitch
- 0.079 2.00mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Mil Conformance
- NO
- Connector Type
- Receptacle
- REACH Uyumluluk Kodu
- unknown
- Reliability
- COMMERCIAL
- Housing Material
- Polybutylene
- Parça Durumu
- Active
- Genişlik
- 2mm
- Ul Flammability Code
- 94V-0
- Yayın Yılı
- 2004
- Fabrika Tedarik Süresi
- 10 Weeks
- Din Conformance
- NO
- Wire Size Min
- 36 AWG
- Yükseklik
- 2mm
- RoHS Durumu
- RoHS Compliant
- Kurşunsuz Kodu
- yes
- Akım Değeri
- 1A
- HTS Kodu
- 8536.69.40.40
- Voltage Rated Ac
- 200V
- Filter Feature
- NO
- Pozisyon Sayısı
- 12
- Contact Materials
- PHOSPHOR BRONZE
- Operating Temperature Min
- -55°C
