A3C-6DA-2DSC(71)

Teknik Özellikler

Nominal Gerilim

200VAC

REACH Uyumluluk Kodu

unknown

Stack Height Mating

5.1mm 6mm

Contact Gender

Female

Style

Board to Board or Cable

Parça Durumu

Active

Çalışma Sıcaklığı

-55°C~85°C

Applications

General Purpose, Telecommunications

Insulation Height

0.165 4.20mm

Insulation Materials

Polybutylene Terephthalate (PBT)

Orientation

Straight

Length Termination

0.079 inch

Fabrika Tedarik Süresi

10 Weeks

Nem Hassasiyeti (MSL)

1 (Unlimited)

Montaj Tipi

Through Hole

Akım Değeri

1A

Row Spacing Mating

0.079 (2.00mm)

Body Breadth

0.157 inch

RoHS Durumu

RoHS Compliant

Kurşunsuz

Lead Free

Material Flammability Rating

UL94 V-0

Number Of Pcb Rows

2

Reference Standard

UL

Connector Type

Receptacle

Contact Length Post

0.079 2.00mm

Fastening Type

Push-Pull

Sıra Sayısı

2

Number Of Positions Loaded

All

Housing Material

Plastic

Pitch Mating

0.079 2.00mm

Yayın Yılı

2004

Durability

100 Cycles

Lead Pitch

2mm

Contact Materials

Phosphor Bronze

Mating Contact Pitch

0.079 inch

Kurşunsuz Kodu

yes

Contact Resistance

15mOhm

Montaj

Through Hole

Contact Shape

Square

Seri

A3
