Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Montaj
- Through Hole
- Contact Resistance
- 15mOhm
- Seri
- A3
- Contact Shape
- Square
- Contact Finish Mating
- Gold
- Rated Current Signal
- 1A
- Reliability
- COMMERCIAL
- Lead Pitch
- 2mm
- Max Voltage Rating Ac
- 200V
- Contact Materials
- Phosphor Bronze
- Kurşunsuz Kodu
- yes
- Mating Contact Pitch
- 0.079 inch
- Pcb Contact Pattern
- RECTANGULAR
- Number Of Conductors
- ONE
- Terminal
- Solder
- Ambalaj
- Tray
- Contact Finish Thickness Post
- 39.4μin 1.00μm
- Pozisyon Sayısı
- 10
- Housing Color
- Black
- Contact Type
- Female Socket
- Contact Finish Post
- Tin
- Polarization Key
- POLARIZED HOUSING
- Depth
- 4mm
- Contact Finish Thickness Mating
- 8.00μin 0.203μm
- Orientation
- Straight
- Fabrika Tedarik Süresi
- 10 Weeks
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj Tipi
- Through Hole
- Akım Değeri
- 1A
- Nominal Gerilim
- 200VAC
- ECCN Kodu
- EAR99
- Stack Height Mating
- 5.1mm 6mm
- REACH Uyumluluk Kodu
- unknown
- Parça Durumu
- Active
- Style
- Board to Board or Cable
- Contact Gender
- Female
- Insulation Height
- 0.165 4.20mm
- Applications
- General Purpose, Telecommunications
- Çalışma Sıcaklığı
- -55°C~85°C
- Insulation Materials
- Polybutylene Terephthalate (PBT)
