A3B-22PA-2DSA(71)

Teknik Özellikler

Contact Finish Thickness Post

78.7μin 2.00μm

Pozisyon Sayısı

22

Contact Type

Male Pin

Contact Finish Post

Tin

Row Spacing Mating

0.079 (2.00mm)

Contact Lengthmating

0.138 3.50mm

Insulation Resistance

1000000000Ohm

Contact Finish Thickness Mating

Flash

Reference Standard

UL

Number Of Pcb Rows

2

Material Flammability Rating

UL94 V-0

RoHS Durumu

RoHS Compliant

Number Of Positions Loaded

All

Sıra Sayısı

2

Contact Length Post

0.102 2.60mm

Connector Type

Header

Fastening Type

Push-Pull

Pcb Contact Pattern

RECTANGULAR

Insulation Color

Black

Pitch Mating

0.079 2.00mm

Terminal

Solder

Ambalaj

Bulk

Yayın Yılı

2008

Number Of Conductors

ONE

Shrouding

Unshrouded

Stack Height Mating

6mm 8.8mm

Overall Contact Length

0.311 7.90mm

REACH Uyumluluk Kodu

unknown

Nominal Gerilim

200VAC

Current Rating Amps

1A

Parça Durumu

Obsolete

Style

Board to Board or Cable

Contact Materials

Brass

Insulation Materials

Polyamide (PA), Nylon

Insulation Height

0.071 1.80mm

Mating Contact Pitch

0.079 inch

Çalışma Sıcaklığı

-55°C~85°C

Seri

A3

Contact Shape

Square

Montaj

Through Hole
