Teknik Özellikler
- Flange Diameter
- 0.187 (4.75mm)
- Uzunluk
- 14.224mm
- Length Above Board
- 0.256 6.50mm
- Contact Finish Thickness
- 137.8μin 3.50μm
- RoHS Durumu
- ROHS3 Compliant
- Rated Current
- 5A
- Terminal Type
- Double End, Pin
- Length Overall
- 0.560 14.22mm
- Insulation
- Insulated
- Montaj Tipi
- Through Hole
- Fabrika Tedarik Süresi
- 10 Weeks
- Material Insulation
- Polytetrafluoroethylene (PTFE)
- Terminal And Terminal Block Type
- PCB TERMINAL
- Yayın Yılı
- 2004
- Board Thickness
- 0.028 ~ 0.063 0.72mm ~ 1.60mm
- Terminal
- Press-Fit
- Number Of Turrets
- Single
- Parça Durumu
- Obsolete
- Nem Hassasiyeti (MSL)
- Not Applicable
- Hole Diameter
- 3.9624 mm
- Fastening Method
- SOLDER
- Contact Finish
- Silver
- HTS Kodu
- 8536.69
- Insulation Color
- White
- Montaj
- Through Hole
- Length Below Flange
- 0.303 7.70mm
- Contact Materials
- Brass
- ECCN Kodu
- EAR99
- Mounting Hole Diameter
- 0.156 (3.96mm)
- Kurşunsuz Kodu
- yes
