M22-7132042

Teknik Özellikler

Reference Standard

UL

Nominal Gerilim

500VAC

Kılıf / Paket

SIL

Fabrika Tedarik Süresi

13 Weeks

Akım Değeri

1A

Number Of Pcb Rows

1

Montaj

Through Hole

Radyasyon Dayanımı

No

Stack Height Mating

5.9mm

Din Conformance

NO

Current Rating Amps

2A

Contact Materials

Phosphor Bronze

Pcb Contact Pattern

RECTANGULAR

Sıra Sayısı

1

Insulation Resistance

5GOhm

Additional Feature

ROHS COMPLIANT

RoHS Durumu

ROHS3 Compliant

Ul Flammability Code

94V-0

Genişlik

450μm

Terminal

Solder

Iec Conformance

NO

Çalışma Sıcaklığı

-40°C~105°C

Insulation Height

0.173 4.40mm

Depth

2.4mm

Contact Finish Mating

Gold

Housing Color

Black

Max Current Rating

1A

Body Breadth

0.094 inch

Max Voltage Rating Ac

500V

Pitch Mating

0.079 2.00mm

Yayın Yılı

2006

Number Of Positions Loaded

All

Contact Length Post

0.094 2.40mm

Contact Resistance

20mOhm

Plating Thickness

50μin

Connector Type

Receptacle

Parça Durumu

Active

Kurşunsuz Kodu

yes

Fastening Type

Push-Pull

Ambalaj

Tube
