Adet bazlı fiyat
- 1+ adet$12.11
- 10+ adet$11.43
- 100+ adet$10.78
- 500+ adet$10.17
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Flammability Rating
- UL94 V-0
- Body Breadth
- 1.339 inch
- Fabrika Tedarik Süresi
- 4 Weeks
- HTS Kodu
- 8536.69.80.00
- Insulation Resistance
- 10GOhm
- ECCN Kodu
- EAR99
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Reference Standard
- UL, CSA
- Additional Feature
- ROHS COMPLIANT
- Terminal Stili
- Screw
- Çalışma Sıcaklığı
- -40°C~125°C
- Mil Conformance
- NO
- Depth
- 32.4mm
- Wire Gauge Max
- 14 AWG
- Working Voltage
- 380V
- Akım Değeri
- 16A
- Gender
- Male
- Renk
- Gray
- Contact Materials
- Copper Alloy
- Voltage Rated Ac
- 380V
- Orientation
- Straight
- Wirecable Gauge
- 14 AWG
- Number Of Conductors
- ONE
- Bodyshell Style
- RECEPTACLE
- Max Current Rating
- 16A
- Housing Material
- Polycarbonate (PC)
- Parça Durumu
- Active
- Reach Svhc
- No SVHC
- Seri
- Han® E
- Contact Style
- RND PIN-SKT
- Material Flammability Rating
- UL94 V-0
- Total Number Of Contacts
- 16
- Uzunluk
- 84.5mm
- Voltage Rated Dc
- 500V
- Test Current
- 16A
- Mixed Contacts
- YES
- Connector Type
- Insert
- Sıra Sayısı
- 2
- Iec Conformance
- NO
- Kurşunsuz Kodu
- yes
