Adet bazlı fiyat
- 1+ adet$21.00
- 10+ adet$19.81
- 100+ adet$18.69
- 500+ adet$17.63
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Flammability Rating
- UL94 V-0
- Din Conformance
- NO
- Sıra Sayısı
- 4
- Seri
- Han® EE
- Insulation Materials
- Polycarbonate
- Kurşunsuz Kodu
- yes
- Mixed Contacts
- YES
- Uzunluk
- 111mm
- HTS Kodu
- 8536.69.80.00
- Gender
- Female
- Iec Conformance
- NO
- Contact Plating
- Silver
- Bodyshell Style
- PLUG
- Number Of Conductors
- ONE
- Pozisyon Sayısı
- 46+Ground
- Depth
- 36.2mm
- Çalışma Sıcaklığı
- -40°C~125°C
- Body Breadth
- 1.339 inch
- Max Current Rating
- 16A
- Contact Type
- Han®
- Ambalaj
- Bulk
- Contact Materials
- Copper
- Dielectric Withstanding Voltage
- 6000VAC V
- Material Flammability Rating
- UL94 V-0
- Connector Type
- Insert without Contacts
- Number Of Contacts
- 46
- Fabrika Tedarik Süresi
- 4 Weeks
- Board Mounting Option
- MOUNTING FLANGE
- Additional Feature
- ROHS COMPL. & M3X10 SCREWS
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj Tipi
- CABLE
- Mounting Option1
- DETENT
- Mil Conformance
- NO
- Voltage Rated Ac
- 500V
- Mounting Option2
- LOCKING
- Orientation
- Straight
- Insulation Resistance
- 1.01kOhm
- Housing Material
- Polycarbonate (PC)
- Working Voltage
- 500V
- Durability
- 500 Cycles
