Adet bazlı fiyat
- 1+ adet$12.35
- 10+ adet$11.65
- 100+ adet$10.99
- 500+ adet$10.37
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Orientation
- Straight
- Reliability
- COMMERCIAL
- Renk
- Gray
- Sıra Sayısı
- 4
- Reference Standard
- UL, CSA
- Contact Plating
- Silver
- Contact Finish Mating
- NOT SPECIFIED
- Contact Resistance
- 1mOhm
- Seri
- Han® EE
- Mounting Option1
- LOCKING
- RoHS Durumu
- ROHS3 Compliant
- ECCN Kodu
- EAR99
- Depth
- 36.2mm
- Connector Type
- Insert without Contacts
- Iec Conformance
- NO
- Total Number Of Contacts
- 10
- Bodyshell Style
- PLUG
- Material Flammability Rating
- UL94 V-0
- Mixed Contacts
- YES
- Wire Gauge Min
- 20 AWG
- Max Current Rating
- 16A
- Akım Değeri
- 16A
- Body Breadth
- 1.339 inch
- Mil Conformance
- NO
- Reach Svhc
- No SVHC
- Flammability Rating
- UL94 V-0
- Number Of Conductors
- ONE
- Insulation Resistance
- 1.01kOhm
- Size
- 6B
- Contact Type
- Han®
- Pin Sayısı
- 10
- Durability
- 500 Cycles
- Fabrika Tedarik Süresi
- 4 Weeks
- Uzunluk
- 51mm
- Din Conformance
- NO
- Wire Gauge Max
- 12 AWG
- Kurşunsuz Kodu
- yes
- HTS Kodu
- 8536.69.80.00
- Voltage Rated Dc
- 500V
- Terminal Stili
- Crimp
