Adet bazlı fiyat
- 1+ adet$22.97
- 10+ adet$21.67
- 100+ adet$20.44
- 500+ adet$19.29
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Size
- 16B
- Insulation Resistance
- 10000000000Ohm
- Durability
- 500 Cycles
- Pin Sayısı
- 6
- Fabrika Tedarik Süresi
- 4 Weeks
- Uzunluk
- 84.5mm
- Din Conformance
- NO
- Bodyshell Style
- RECEPTACLE
- Total Number Of Contacts
- 6
- Mixed Contacts
- YES
- Material Flammability Rating
- UL94 V-0
- Test Current
- 35A
- Max Current Rating
- 35A
- Reach Svhc
- No SVHC
- Mil Conformance
- NO
- Body Breadth
- 1.339 inch
- Akım Değeri
- 35A
- Wirecable Gauge
- 10 AWG
- Number Of Conductors
- ONE
- Flammability Rating
- UL94 V-0
- Contact Resistance
- 500000mOhm
- Depth
- 34mm
- RoHS Durumu
- ROHS3 Compliant
- Mounting Option1
- M3
- Seri
- Han® HsB
- Connector Type
- Insert
- Iec Conformance
- NO
- Contact Finish
- Silver
- Reliability
- COMMERCIAL
- Orientation
- Straight
- Reference Standard
- UL, CSA
- Sıra Sayısı
- 2
- Renk
- Gray
- Additional Feature
- ROHS COMPLIANT
- Housing Material
- Polycarbonate (PC)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Parça Durumu
- Active
- Voltage Rated Ac
- 380V
- Contact Materials
- Copper Alloy
- Working Voltage
- 380V
