Adet bazlı fiyat
- 1+ adet$8.66
- 10+ adet$8.17
- 100+ adet$7.70
- 500+ adet$7.27
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Kurşunsuz
- Lead Free
- Voltage Rated Ac
- 250V
- Fabrika Tedarik Süresi
- 4 Weeks
- Seri
- Han® B
- Durability
- 500 Cycles
- Kurşunsuz Kodu
- yes
- Mounting Option1
- M3
- ECCN Kodu
- EAR99
- Insulation Resistance
- 10GOhm
- Flammability Rating
- UL94 V-0
- Body Breadth
- 1.339 inch
- Parça Durumu
- Active
- Orientation
- Straight
- Wire Gauge Min
- 26 AWG
- Contact Finish Mating
- NOT SPECIFIED
- Iec Conformance
- NO
- Contact Type
- Han® D
- Renk
- Gray
- Reach Svhc
- No SVHC
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Number Of Conductors
- ONE
- Test Voltage
- 2kV
- Connector Type
- Insert without Contacts
- Uzunluk
- 84.5mm
- Contact Resistance
- 3MOhm
- Mounting Option2
- LOCKING
- Working Voltage
- 250V
- Çalışma Sıcaklığı
- -40°C~125°C
- Din Conformance
- YES
- Housing Material
- Polycarbonate (PC)
- Test Current
- 10A
- Size
- 16B
- Number Of Poles
- 40
- Reliability
- COMMERCIAL
- Akım Değeri
- 10A
- Voltage Rated Dc
- 250V
- Mixed Contacts
- YES
- Mil Conformance
- NO
- Ambalaj
- Bulk
- Ratings
- IP65
