Adet bazlı fiyat
- 1+ adet$7.46
- 10+ adet$7.04
- 100+ adet$6.64
- 500+ adet$6.26
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Orientation
- Straight
- Wire Gauge Min
- 26 AWG
- Contact Finish Mating
- NOT SPECIFIED
- Parça Durumu
- Active
- Iec Conformance
- NO
- Renk
- Gray
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Reach Svhc
- No SVHC
- Contact Type
- Han® D
- Number Of Conductors
- ONE
- Test Voltage
- 2kV
- Connector Type
- Insert without Contacts
- Uzunluk
- 73mm
- Dielectric Withstanding Voltage
- 4000VAC V
- Contact Resistance
- 3MOhm
- Mounting Option2
- LOCKING
- Operating Supply Voltage
- 600V
- Voltage Rated Ac
- 250V
- Fabrika Tedarik Süresi
- 3 Weeks
- Kurşunsuz
- Lead Free
- Seri
- Han® D
- Kurşunsuz Kodu
- yes
- Durability
- 500 Cycles
- Mounting Option1
- DETENT
- Insulation Resistance
- 10GOhm
- ECCN Kodu
- EAR99
- Flammability Rating
- UL94 HB
- Body Breadth
- 0.898 inch
- Sıra Sayısı
- 3
- Contact Plating
- Silver
- Gender
- Female
- Terminal Stili
- Crimp
- Pin Sayısı
- 25
- Material Flammability Rating
- UL94 HB
- RoHS Durumu
- ROHS3 Compliant
- Max Current Rating
- 10A
- Option
- GENERAL PURPOSE
- Bodyshell Style
- PLUG
- Total Number Of Contacts
- 25
- Çalışma Sıcaklığı
- -40°C~125°C
