Adet bazlı fiyat
- 1+ adet$15.12
- 10+ adet$14.26
- 100+ adet$13.45
- 500+ adet$12.69
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Durability
- 500 Cycles
- Kurşunsuz Kodu
- yes
- Seri
- Han® D
- Voltage Rated Ac
- 250V
- Fabrika Tedarik Süresi
- 4 Weeks
- Kurşunsuz
- Lead Free
- Flammability Rating
- UL94 HB
- Body Breadth
- 0.898 inch
- Insulation Resistance
- 10GOhm
- Mounting Option1
- DETENT
- Renk
- Gray
- Reach Svhc
- No SVHC
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Type
- Han® D
- Iec Conformance
- NO
- Wire Gauge Min
- 26 AWG
- Orientation
- Straight
- Contact Finish Mating
- NOT SPECIFIED
- Parça Durumu
- Active
- Contact Resistance
- 3MOhm
- Mounting Option2
- LOCKING
- Uzunluk
- 56.5mm
- Connector Type
- Insert without Contacts
- Dielectric Withstanding Voltage
- 4000VAC V
- Test Voltage
- 2kV
- Number Of Conductors
- ONE
- Reliability
- COMMERCIAL
- Akım Değeri
- 10A
- Housing Material
- Polyamide (PA), Nylon
- Test Current
- 10A
- Din Conformance
- NO
- Çalışma Sıcaklığı
- -40°C~125°C
- Working Voltage
- 250V
- Pozisyon Sayısı
- 15+Ground
- Wire Gauge Max
- 14 AWG
- Montaj Tipi
- CABLE
- Depth
- 33mm
- Reference Standard
- UL, CSA
- Board Mounting Option
- MOUNTING FLANGE
- Contact Materials
- Copper
