Adet bazlı fiyat
- 1+ adet$15.12
- 10+ adet$14.26
- 100+ adet$13.45
- 500+ adet$12.69
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Mixed Contacts
- YES
- Voltage Rated Dc
- 250V
- Mil Conformance
- NO
- Ambalaj
- Bulk
- Ratings
- IP65
- Board Mounting Option
- MOUNTING FLANGE
- Contact Materials
- Copper
- Wire Gauge Max
- 14 AWG
- Montaj Tipi
- CABLE
- Depth
- 33.7mm
- Reference Standard
- UL, CSA
- Pozisyon Sayısı
- 15+Ground
- Working Voltage
- 250V
- Çalışma Sıcaklığı
- -40°C~125°C
- Din Conformance
- NO
- Housing Material
- Polyamide (PA), Nylon
- Test Current
- 10A
- Material
- Polyamide
- Number Of Poles
- 15
- Akım Değeri
- 10A
- Reliability
- COMMERCIAL
- RoHS Durumu
- ROHS3 Compliant
- Material Flammability Rating
- UL94 HB
- Bodyshell Style
- RECEPTACLE
- Max Current Rating
- 10A
- Option
- GENERAL PURPOSE
- Total Number Of Contacts
- 15
- Contact Plating
- Silver
- Gender
- Male
- Sıra Sayısı
- 3
- Terminal Stili
- Crimp
- Mounting Option1
- GUIDE SLOT
- ECCN Kodu
- EAR99
- Insulation Resistance
- 10GOhm
- Flammability Rating
- UL94 HB
- Body Breadth
- 0.898 inch
- Kurşunsuz
- Lead Free
- Fabrika Tedarik Süresi
- 4 Weeks
- Voltage Rated Ac
- 250V
- Seri
- Han® D
