09195167324

Teknik Özellikler

Body Breadth

0.366 inch

Filter Feature

NO

Mil Conformance

NO

Nem Hassasiyeti (MSL)

1 (Unlimited)

Connector Type

Header

Terminal

Solder

Ul Flammability Code

94V-0

Akım Değeri

2A

Number Of Conductors

ONE

Contact Finish Post

Tin

Style

Board to Cable/Wire

Voltage Rated Dc

350V

Insulation Resistance

1GOhm

Working Voltage

350V

Ambalaj

Bulk

Parça Durumu

Active

Renk

Grey

Insulation Height

0.350 8.89mm

Mating Contact Pitch

0.1 inch

Mixed Contacts

NO

Polarization Key

POLARIZED HOUSING

Reach Svhc

No SVHC

Sıra Sayısı

2

Contact Resistance

20mOhm

Contact Lengthmating

0.240 6.10mm

Rated Current Signal

2A

Contact Type

Male Pin

Contact Shape

Square

Number Of Positions Loaded

All

Pcb Contact Pattern

RECTANGULAR

Number Of Poles

16

Contact Plating

Gold

Insulation Color

Beige

Iec Conformance

YES

Reliability

COMMERCIAL

Contact Materials

Copper Alloy

RoHS Durumu

ROHS3 Compliant

Row Spacing Mating

0.100 (2.54mm)

Durability

50 Cycles

Voltage Rated Ac

350V
