09195107323

Teknik Özellikler

Number Of Conductors

ONE

Akım Değeri

2A

Style

Board to Cable/Wire

Mil Conformance

NO

Filter Feature

NO

Terminal

Solder

Ul Flammability Code

94V-0

Nem Hassasiyeti (MSL)

1 (Unlimited)

Connector Type

Header

Parça Durumu

Active

Ambalaj

Bulk

Insulation Height

0.366 9.30mm

Renk

Grey

Working Voltage

350V

Insulation Resistance

1GOhm

Voltage Rated Dc

350V

Sıra Sayısı

2

Contact Lengthmating

0.240 6.10mm

Contact Resistance

20mOhm

Mixed Contacts

NO

Mating Contact Pitch

0.1 inch

Reach Svhc

No SVHC

Polarization Key

CTR W/GUIDE SLOTS

Contact Plating

Gold

Number Of Poles

10

Contact Type

Male Pin

Contact Shape

Square

Rated Current Signal

1A

Pcb Contact Pattern

RECTANGULAR

Number Of Positions Loaded

All

Reliability

COMMERCIAL

Iec Conformance

YES

Row Spacing Mating

0.100 (2.54mm)

RoHS Durumu

ROHS3 Compliant

Contact Materials

Copper Alloy

Insulation Color

Beige

Seri

SEK

Fastening Type

Latch Holder

Option

GENERAL PURPOSE

Voltage Rated Ac

350V
