09185607324

Teknik Özellikler

Polarization Key

POLARIZED HOUSING

Ul Flammability Code

94V-0

Özellikler

Keying Slot

Contact Type

Male Pin

Contact Finish Mating

NOT SPECIFIED

Insulation Materials

Polybutylene Terephthalate (PBT), Glass Filled

Voltage Rated Dc

350V

Number Of Pcb Rows

2

Gender

Male

Contact Finish Post

Tin

Sıra Sayısı

2

Nem Hassasiyeti (MSL)

1 (Unlimited)

Contact Shape

Square

Option

GENERAL PURPOSE

Din Conformance

YES

Fabrika Tedarik Süresi

7 Weeks

Working Voltage

350V

Shrouding

Shrouded - 4 Wall

Renk

Grey

Iec Conformance

YES

Contact Lengthmating

0.242 6.15mm

Contact Materials

Copper Alloy

Material Flammability Rating

UL94 V-0

Akım Değeri

1A

Ambalaj

Bulk

Hole Diameter

900 μm

Reliability

COMMERCIAL

Row Spacing Mating

0.100 (2.54mm)

Pcb Contact Pattern

RECTANGULAR

Montaj Tipi

Through Hole

Terminal

Solder

Flammability Rating

UL94 V-0

Insulation Height

0.350 8.89mm

Montaj

Through Hole

Lead Pitch

2.54mm

Voltage Rated Ac

350V

Insulation Color

Gray

Seri

SEK

Durability

50 Cycles

Connector Type

Header
