Adet bazlı fiyat
- 1+ adet$4.53
- 10+ adet$4.27
- 100+ adet$4.03
- 500+ adet$3.80
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Hole Diameter
- 900 μm
- Reliability
- COMMERCIAL
- Pcb Contact Pattern
- RECTANGULAR
- Row Spacing Mating
- 0.100 (2.54mm)
- Montaj Tipi
- Through Hole
- Terminal
- Solder
- Ambalaj
- Tray
- Genişlik
- 71.3mm
- Material Flammability Rating
- UL94 V-0
- Akım Değeri
- 2A
- Contact Lengthmating
- 0.240 6.10mm
- Yükseklik
- 12.35mm
- Contact Materials
- Copper Alloy
- Renk
- Grey
- Iec Conformance
- YES
- Working Voltage
- 350V
- Shrouding
- Shrouded - 4 Wall
- Din Conformance
- YES
- Fabrika Tedarik Süresi
- 4 Weeks
- Contact Shape
- Square
- Option
- GENERAL PURPOSE
- Sıra Sayısı
- 2
- Housing Material
- Polyester
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Number Of Pcb Rows
- 2
- Contact Finish Post
- Tin
- Test Voltage
- 1kV
- Insulation Materials
- Polybutylene Terephthalate (PBT), Glass Filled
- Voltage Rated Dc
- 350V
- Contact Finish Mating
- NOT SPECIFIED
- Contact Type
- Male Pin
- Contact Gender
- Male
- Özellikler
- Keying Slot
- Ul Flammability Code
- 94V-0
- Polarization Key
- POLARIZED HOUSING
- Mixed Contacts
- NO
- Fastening Type
- Latch Holder
- Rated Current Signal
- 2A
- Number Of Poles
- 50
- Contact Plating
- Gold
