09185347904

Teknik Özellikler

Polarization Key

CTR W/GUIDE SLOTS

Özellikler

Keying Slot, Mounting Flange

Ul Flammability Code

94V-0

Contact Type

Male Pin

Contact Finish Mating

NOT SPECIFIED

Insulation Materials

Polybutylene Terephthalate (PBT), Glass Filled

Voltage Rated Dc

350V

Number Of Pcb Rows

2

Contact Finish Post

Tin

Gender

Male

Nem Hassasiyeti (MSL)

1 (Unlimited)

Sıra Sayısı

2

Contact Shape

Square

Option

GENERAL PURPOSE

ECCN Kodu

EAR99

Din Conformance

YES

Fabrika Tedarik Süresi

4 Weeks

Working Voltage

350V

Shrouding

Shrouded - 4 Wall

Iec Conformance

NO

Renk

Grey

Contact Lengthmating

0.228 5.80mm

Contact Materials

Copper Alloy

Material Flammability Rating

UL94 V-0

Akım Değeri

1A

Ambalaj

Bulk

Pcb Contact Pattern

RECTANGULAR

Row Spacing Mating

0.100 (2.54mm)

Hole Diameter

900 μm

Reliability

COMMERCIAL

Terminal

Solder

Montaj Tipi

Through Hole

Insulation Height

0.681 17.30mm

Montaj

Through Hole

Flammability Rating

UL94 V-0

Voltage Rated Ac

350V

Lead Pitch

2.54mm

Dielectric Withstanding Voltage

1000VAC V

Insulation Color

Gray

Durability

50 Cycles
