Adet bazlı fiyat
- 1+ adet$1.76
- 10+ adet$1.66
- 100+ adet$1.57
- 500+ adet$1.48
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Filter Feature
- NO
- Connector Type
- Header
- Insulation Resistance
- 1GOhm
- Parça Durumu
- Active
- Mating Contact Pitch
- 0.1 inch
- Insulation Color
- Gray
- Seri
- SEK
- Flammability Rating
- UL94 V-0
- Montaj
- Through Hole
- Insulation Height
- 0.335 8.51mm
- Lead Pitch
- 2.54mm
- Contact Current Rating
- 1A
- Voltage Rated Ac
- 350V
- Uzunluk
- 52.6mm
- Additional Feature
- STANDARDS: IEC 60603-13; DIN EN 60603-13, POLARIZED
- Reach Svhc
- No SVHC
- Çalışma Sıcaklığı
- -55°C~125°C
- Depth
- 25.75mm
- Body Breadth
- 0.335 inch
- RoHS Durumu
- ROHS3 Compliant
- Number Of Conductors
- ONE
- Number Of Positions Loaded
- All
- Contact Length Post
- 0.114 2.90mm
- HTS Kodu
- 8536.69.40.40
- Pitch Mating
- 0.100 2.54mm
- Mixed Contacts
- NO
- Fastening Type
- Latch Lock/Eject Hooks, Long
- Rated Current Signal
- 2A
- Contact Plating
- Gold
- Number Of Poles
- 26
- Contact Resistance
- 20mOhm
- Reference Standard
- UL
- Kurşunsuz Kodu
- yes
- Style
- Board to Cable/Wire
- Mil Conformance
- NO
- Orientation
- Right Angle
- Contact Finish Mating
- NOT SPECIFIED
- Contact Type
- Male Pin
- Contact Gender
- Male
- Özellikler
- Keying Slot, Mounting Flange
