09185266329

Teknik Özellikler

Contact Finish Mating

NOT SPECIFIED

Contact Type

Male Pin

Operating Temperature Min

-55°C

Özellikler

Keying Slot

Ul Flammability Code

94V-0

Polarization Key

POLARIZED HOUSING

Option

GENERAL PURPOSE

Contact Shape

Square

Nem Hassasiyeti (MSL)

1 (Unlimited)

Sıra Sayısı

2

Contact Finish Post

Tin

Gender

Male

Number Of Pcb Rows

2

Insulation Materials

Polybutylene Terephthalate (PBT), Glass Filled

Contact Materials

Copper Alloy

Contact Lengthmating

0.240 6.10mm

Iec Conformance

NO

Renk

Grey

Shrouding

Shrouded - 4 Wall

Body Length Or Diameter

1.606 inch

Fabrika Tedarik Süresi

7 Weeks

Din Conformance

YES

Terminal

Press-Fit, Solder

Montaj Tipi

Through Hole

Row Spacing Mating

0.100 (2.54mm)

Pcb Contact Pattern

RECTANGULAR

Reliability

COMMERCIAL

Ambalaj

Bulk

Akım Değeri

2A

Material Flammability Rating

UL94 V-0

Filter Feature

NO

Mating Contact Pitch

0.1 inch

Parça Durumu

Active

Connector Type

Header

Insulation Resistance

1000000000Ohm

Seri

SEK

Pozisyon Sayısı

26

Insulation Color

Gray

Insulation Height

0.350 8.89mm

Montaj

Through Hole
