Adet bazlı fiyat
- 1+ adet$1.50
- 10+ adet$1.41
- 100+ adet$1.33
- 500+ adet$1.26
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Polarization Key
- POLARIZED HOUSING
- Özellikler
- Keying Slot, Mounting Flange
- Ul Flammability Code
- 94V-0
- Contact Type
- Male Pin
- Contact Gender
- Male
- Contact Finish Mating
- NOT SPECIFIED
- Insulation Materials
- Polybutylene Terephthalate (PBT), Glass Filled
- Voltage Rated Dc
- 350V
- Number Of Pcb Rows
- 2
- Sıra Sayısı
- 2
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Shape
- Square
- Option
- GENERAL PURPOSE
- Din Conformance
- YES
- Fabrika Tedarik Süresi
- 4 Weeks
- Working Voltage
- 350V
- Shrouding
- Shrouded - 4 Wall
- Renk
- Grey
- Kurşunsuz
- Lead Free
- Iec Conformance
- NO
- Contact Lengthmating
- 0.240 6.10mm
- Contact Materials
- Copper Alloy
- Material Flammability Rating
- UL94 V-0
- Akım Değeri
- 2A
- Ambalaj
- Tray
- Reliability
- COMMERCIAL
- Hole Diameter
- 900 μm
- Row Spacing Mating
- 0.100 (2.54mm)
- Pcb Contact Pattern
- RECTANGULAR
- Montaj Tipi
- Through Hole, Right Angle
- Terminal
- Solder
- Flammability Rating
- UL94 V-0
- Insulation Height
- 0.335 8.51mm
- Montaj
- Through Hole
- Lead Pitch
- 2.54mm
- Contact Current Rating
- 1A
- Voltage Rated Ac
- 350V
- Insulation Color
- Gray
- Seri
- SEK
- Connector Type
- Header
