Adet bazlı fiyat
- 1+ adet$1.12
- 10+ adet$1.06
- 100+ adet$1.00
- 500+ adet$0.94
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Lead Pitch
- 2.54mm
- Montaj
- Cable, Free Hanging
- Seri
- SEK
- Parça Durumu
- Active
- Connector Type
- Receptacle
- Insulation Resistance
- 1000000000Ohm
- Bodyshell Style
- PLUG
- Wire Gauge Min
- 26 AWG
- Wire Gauge
- 26-28 AWG
- Filter Feature
- NO
- Wire Gauge Max
- 28 AWG
- RoHS Durumu
- ROHS3 Compliant
- Depth
- 6.1mm
- Reach Svhc
- No SVHC
- Uzunluk
- 30mm
- Additional Feature
- STANDARD: IEC 60603-13; DIN EN 60603-13, POLARIZED
- Orientation
- Right Angle
- Mil Conformance
- NO
- Kurşunsuz Kodu
- yes
- Reference Standard
- UL
- Number Of Poles
- 20
- Contact Plating
- Gold
- Rated Current Signal
- 2A
- Mixed Contacts
- NO
- Polarization Key
- CENTER
- Ul Flammability Code
- 94V-0
- Özellikler
- Feed Through, Polarizing Key
- Row Spacing
- 0.100 (2.54mm)
- Contact Gender
- Female
- Contact Type
- Female Socket
- Operating Temperature Min
- -55°C
- Contact Finish Mating
- NOT SPECIFIED
- Cable Termination
- IDC
- Insulation Materials
- PBTP 30% FIBRE ENHANCED
- Total Number Of Contacts
- 20
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Sıra Sayısı
- 2
- Option
- GENERAL PURPOSE
- Fabrika Tedarik Süresi
- 4 Weeks
- Din Conformance
- YES
