Adet bazlı fiyat
- 1+ adet$1.90
- 10+ adet$1.79
- 100+ adet$1.69
- 500+ adet$1.59
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Connector Type
- Header
- Insulation Resistance
- 1000000000Ohm
- Max Current Rating
- 1A
- Parça Durumu
- Active
- Mating Contact Pitch
- 0.1 inch
- Filter Feature
- NO
- Insulation Height
- 0.681 17.30mm
- Montaj
- Through Hole
- Insulation Color
- Gray
- Pozisyon Sayısı
- 16
- Seri
- SEK
- Reach Svhc
- No SVHC
- Çalışma Sıcaklığı
- -55°C~125°C
- Uzunluk
- 39.9mm
- Additional Feature
- STANDARDS: DIN EN 60603-13; IEC 60603-13, POLARIZED
- RoHS Durumu
- ROHS3 Compliant
- Number Of Conductors
- ONE
- Depth
- 8.5mm
- Body Breadth
- 0.335 inch
- Lead Length
- 29mm
- Number Of Positions Loaded
- All
- Contact Length Post
- 0.114 2.90mm
- Pitch Mating
- 0.100 2.54mm
- Fastening Type
- Latch Lock/Eject Hooks, Short
- Rated Current Signal
- 2A
- Contact Plating
- Gold
- Overall Contact Length
- 0.650 16.51mm
- Mixed Contacts
- NO
- Kurşunsuz Kodu
- yes
- Style
- Board to Cable/Wire
- Mil Conformance
- NO
- Orientation
- Straight
- Contact Resistance
- 20mOhm
- Reference Standard
- UL
- Contact Type
- Male Pin
- Contact Gender
- Male
- Manufacturer Package Identifier
- TB 09 18 516 X91X
- Contact Finish Mating
- NOT SPECIFIED
- Polarization Key
- POLARIZED HOUSING
- Ul Flammability Code
- 94V-0
