09185166902

Teknik Özellikler

Pcb Contact Pattern

RECTANGULAR

Row Spacing Mating

0.100 (2.54mm)

Reliability

COMMERCIAL

Terminal

Solder

Montaj Tipi

Through Hole

Material Flammability Rating

UL94 V-0

Ambalaj

Bulk

Iec Conformance

NO

Renk

Grey

Contact Lengthmating

0.240 6.10mm

Contact Materials

Copper Alloy

Din Conformance

YES

ECCN Kodu

EAR99

Fabrika Tedarik Süresi

7 Weeks

Shrouding

Shrouded - 4 Wall

Nem Hassasiyeti (MSL)

1 (Unlimited)

Sıra Sayısı

2

Contact Shape

Square

Option

GENERAL PURPOSE

Insulation Materials

Polybutylene Terephthalate (PBT), Glass Filled

Number Of Pcb Rows

2

Gender

Male

Contact Finish Post

Tin

Contact Type

Male Pin

Contact Finish Mating

NOT SPECIFIED

Polarization Key

CTR W/GUIDE SLOTS

Ul Flammability Code

94V-0

Özellikler

Keying Slot, Mounting Flange

Rated Current Signal

1A

Fastening Type

Latch Lock/Eject Hooks, Long

Overall Contact Length

0.713 18.10mm

Mixed Contacts

NO

Style

Board to Cable/Wire

Kurşunsuz Kodu

yes

Orientation

Straight

Mil Conformance

NO

Reference Standard

UL

Contact Length Post

0.177 4.50mm

Number Of Positions Loaded

All

Pitch Mating

0.100 2.54mm
