Adet bazlı fiyat
- 1+ adet$1.93
- 10+ adet$1.82
- 100+ adet$1.72
- 500+ adet$1.62
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Fabrika Tedarik Süresi
- 7 Weeks
- ECCN Kodu
- EAR99
- Din Conformance
- YES
- Body Length Or Diameter
- 0.98 inch
- Iec Conformance
- YES
- Contact Materials
- Thermoplastic
- Pitch
- 0.100 2.54mm
- Akım Değeri
- 2A
- Wire Type
- Ribbon Cable
- Ambalaj
- Bulk
- Montaj Tipi
- Free Hanging (In-Line)
- Reliability
- COMMERCIAL
- Wirecable Type
- Ribbon
- Polarization Key
- CENTER
- Ul Flammability Code
- 94V-0
- Özellikler
- Closed End, Polarizing Key
- Row Spacing
- 0.100 (2.54mm)
- Contact Gender
- Female
- Nominal Gerilim
- 320V
- Operating Temperature Min
- -55°C
- Contact Type
- Female Socket
- Contact Finish Mating
- NOT SPECIFIED
- Cable Termination
- IDC
- Insulation Materials
- PBTP 30% FIBRE ENHANCED
- Total Number Of Contacts
- 16
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Sıra Sayısı
- 2
- Option
- GENERAL PURPOSE
- HTS Kodu
- 8536.69.40.40
- Mil Conformance
- NO
- Orientation
- Straight
- Kurşunsuz Kodu
- yes
- Reference Standard
- UL
- Rated Current Signal
- 2A
- Mixed Contacts
- NO
- Montaj
- Free Hanging
- Seri
- SEK
- Pozisyon Sayısı
- 16
- Parça Durumu
- Active
- Insulation Resistance
- 1000000000Ohm
