09185165803

Teknik Özellikler

Polarization Key

CENTER

Özellikler

Feed Through, Polarizing Key

Ul Flammability Code

94V-0

Operating Temperature Min

-55°C

Contact Finish Thickness

30.0μin 0.76μm

Contact Type

Female Socket

Row Spacing

0.100 (2.54mm)

Cable Termination

IDC

Insulation Materials

PBTP 30% FIBRE ENHANCED

Total Number Of Contacts

16

Gender

Female

Nem Hassasiyeti (MSL)

1 (Unlimited)

Sıra Sayısı

2

Option

GENERAL PURPOSE

ECCN Kodu

EAR99

Din Conformance

YES

Fabrika Tedarik Süresi

7 Weeks

Body Length Or Diameter

0.98 inch

Iec Conformance

YES

Pitch

0.100 2.54mm

Contact Materials

NOT SPECIFIED

Wire Type

Ribbon Cable

Akım Değeri

2A

Ambalaj

Bulk

Wirecable Type

Ribbon

Reliability

COMMERCIAL

Montaj Tipi

Free Hanging (In-Line)

Contact Design

PREASSEM CONN

Montaj

Free Hanging

Pozisyon Sayısı

16

Seri

SEK

Connector Type

Receptacle

Insulation Resistance

1000000000Ohm

Parça Durumu

Active

Contact Finish

Gold

Wire Gauge

26-28 AWG

Filter Feature

NO

Bodyshell Style

PLUG

Wire Gauge Min

26 AWG

RoHS Durumu

ROHS3 Compliant
