Adet bazlı fiyat
- 1+ adet$0.87
- 10+ adet$0.82
- 100+ adet$0.77
- 500+ adet$0.73
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Voltage Rated Dc
- 350V
- Total Number Of Contacts
- 10
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Housing Material
- Polybutylene
- Sıra Sayısı
- 2
- Option
- GENERAL PURPOSE
- Polarization Key
- CENTER
- Özellikler
- Feed Through, Polarizing Key, Strain Relief
- Ul Flammability Code
- 94V-0
- Row Spacing
- 0.100 (2.54mm)
- Contact Type
- Female Socket
- Contact Finish Mating
- NOT SPECIFIED
- Min. Çalışma Sıcaklığı
- -55°C
- Cable Termination
- IDC
- Akım Değeri
- 2A
- Wire Type
- Ribbon Cable
- Ambalaj
- Bulk
- Terminal
- IDT
- Montaj Tipi
- Free Hanging (In-Line)
- Reliability
- COMMERCIAL
- Wirecable Type
- Ribbon
- Contact Design
- PREASSEM CONN
- Fabrika Tedarik Süresi
- 4 Weeks
- Din Conformance
- YES
- Mating Information
- NO
- Iec Conformance
- YES
- Renk
- Grey
- Contact Materials
- Brass
- Pitch
- 0.100 2.54mm
- Wire Gauge Max
- 28 AWG
- RoHS Durumu
- ROHS3 Compliant
- Depth
- 7.2mm
- Reach Svhc
- No SVHC
- Additional Feature
- STANDARD: IEC 60603-13; DIN EN 60603-13, POLARIZED
- Uzunluk
- 17.3mm
- Contact Current Rating
- 1A
- Voltage Rated Ac
- 350V
- Lead Pitch
- 2.54mm
- Montaj
- Cable, Free Hanging
- Flammability Rating
- UL94 V-0
