Adet bazlı fiyat
- 1+ adet$1.90
- 10+ adet$1.79
- 100+ adet$1.69
- 500+ adet$1.59
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Polarization Key
- POLARIZED HOUSING
- Özellikler
- Keying Slot
- Ul Flammability Code
- 94V-0
- Contact Type
- Male Pin
- Contact Finish Mating
- NOT SPECIFIED
- Insulation Materials
- Polybutylene Terephthalate (PBT), Glass Filled
- Contact Finish Post
- Tin
- Gender
- Male
- Number Of Pcb Rows
- 2
- Sıra Sayısı
- 2
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Option
- GENERAL PURPOSE
- Contact Shape
- Square
- Fabrika Tedarik Süresi
- 7 Weeks
- Din Conformance
- YES
- ECCN Kodu
- EAR99
- Shrouding
- Shrouded - 4 Wall
- Kurşunsuz
- Lead Free
- Iec Conformance
- YES
- Contact Materials
- Copper Alloy
- Contact Lengthmating
- 0.240 6.10mm
- Material Flammability Rating
- UL94 V-0
- Ambalaj
- Bulk
- Montaj Tipi
- Through Hole
- Terminal
- Solder
- Reliability
- COMMERCIAL
- Pcb Contact Pattern
- RECTANGULAR
- Row Spacing Mating
- 0.100 (2.54mm)
- Insulation Height
- 0.350 8.89mm
- Montaj
- Through Hole
- Seri
- SEK
- Durability
- 50 Cycles
- Insulation Color
- Gray
- Pozisyon Sayısı
- 10
- Parça Durumu
- Active
- Mating Contact Pitch
- 0.1 inch
- Connector Type
- Header
- Filter Feature
- NO
- Number Of Conductors
- ONE
- RoHS Durumu
- ROHS3 Compliant
