Adet bazlı fiyat
- 1+ adet$1.79
- 10+ adet$1.69
- 100+ adet$1.60
- 500+ adet$1.51
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Iec Conformance
- YES
- Renk
- Grey
- Contact Lengthmating
- 0.240 6.10mm
- Contact Materials
- Copper Alloy
- ECCN Kodu
- EAR99
- Din Conformance
- YES
- Fabrika Tedarik Süresi
- 7 Weeks
- Shrouding
- Shrouded - 4 Wall
- Pcb Contact Pattern
- RECTANGULAR
- Row Spacing Mating
- 0.100 (2.54mm)
- Reliability
- COMMERCIAL
- Terminal
- Solder
- Montaj Tipi
- Through Hole
- Material Flammability Rating
- UL94 V-0
- Akım Değeri
- 2A
- Ambalaj
- Tray
- Contact Type
- Male Pin
- Contact Finish Mating
- NOT SPECIFIED
- Polarization Key
- POLARIZED HOUSING
- Ul Flammability Code
- 94V-0
- Özellikler
- Keying Slot, Mounting Flange
- Housing Material
- Polybutylene
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Sıra Sayısı
- 2
- Contact Shape
- Square
- Option
- GENERAL PURPOSE
- Insulation Materials
- Polybutylene Terephthalate (PBT), Glass Filled
- Test Voltage
- 1kV
- Number Of Pcb Rows
- 2
- Contact Finish Post
- Tin
- Gender
- Male
- Contact Length Post
- 0.114 2.90mm
- Number Of Positions Loaded
- All
- Pitch Mating
- 0.100 2.54mm
- HTS Kodu
- 8536.69.40.40
- Rated Current Signal
- 2A
- Fastening Type
- Push-Pull
- Contact Plating
- Gold
- Mixed Contacts
- NO
- Overall Contact Length
- 0.650 16.51mm
