Adet bazlı fiyat
- 1+ adet$1.92
- 10+ adet$1.81
- 100+ adet$1.71
- 500+ adet$1.61
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Fabrika Tedarik Süresi
- 7 Weeks
- Din Conformance
- YES
- Body Length Or Diameter
- 0.681 inch
- Iec Conformance
- YES
- Contact Materials
- Copper
- Pitch
- 0.100 2.54mm
- Mil Conformance
- NO
- Wire Type
- Ribbon Cable
- Kurşunsuz Kodu
- yes
- Ambalaj
- Bulk
- Reference Standard
- UL
- Montaj Tipi
- Free Hanging (In-Line)
- Reliability
- COMMERCIAL
- Wirecable Type
- Ribbon
- Rated Current Signal
- 2A
- Contact Design
- PREASSEM CONN
- Mixed Contacts
- NO
- Polarization Key
- CENTER
- Montaj
- Free Hanging
- Seri
- SEK
- Ul Flammability Code
- 94V-0
- Özellikler
- Closed End, Polarizing Key, Strain Relief
- Pozisyon Sayısı
- 10
- Parça Durumu
- Active
- Row Spacing
- 0.100 (2.54mm)
- Connector Type
- Receptacle
- Operating Temperature Min
- -55°C
- Contact Type
- Female Socket
- Wire Gauge Min
- 26 AWG
- Contact Finish Mating
- NOT SPECIFIED
- Bodyshell Style
- PLUG
- Wire Gauge
- 26-28 AWG
- Cable Termination
- IDC
- Filter Feature
- NO
- Wire Gauge Max
- 28 AWG
- Insulation Materials
- PBTP 30% FIBRE ENHANCED
- RoHS Durumu
- ROHS3 Compliant
- Total Number Of Contacts
- 10
- Sıra Sayısı
- 2
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
