Adet bazlı fiyat
- 1+ adet$0.71
- 10+ adet$0.67
- 100+ adet$0.63
- 500+ adet$0.60
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Shrouding
- Shrouded - 4 Wall
- Working Voltage
- 350V
- Fabrika Tedarik Süresi
- 4 Weeks
- Din Conformance
- YES
- Contact Materials
- Copper Alloy
- Yükseklik
- 9.45mm
- Contact Lengthmating
- 0.240 6.10mm
- Iec Conformance
- YES
- Renk
- Grey
- Ambalaj
- Bulk
- Akım Değeri
- 1A
- Material Flammability Rating
- UL94 V-0
- Terminal
- Solder
- Montaj Tipi
- Through Hole
- Pcb Contact Pattern
- RECTANGULAR
- Row Spacing Mating
- 0.100 (2.54mm)
- Hole Diameter
- 900 μm
- Reliability
- COMMERCIAL
- Ul Flammability Code
- 94V-0
- Özellikler
- Keying Slot
- Polarization Key
- POLARIZED HOUSING
- Contact Finish Mating
- NOT SPECIFIED
- Contact Type
- Male Pin
- Contact Finish Post
- Tin
- Number Of Pcb Rows
- 2
- Voltage Rated Dc
- 350V
- Insulation Materials
- Polybutylene Terephthalate (PBT), Glass Filled
- Option
- GENERAL PURPOSE
- Contact Shape
- Square
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Sıra Sayısı
- 2
- Pitch Mating
- 0.100 2.54mm
- Number Of Positions Loaded
- All
- Contact Length Post
- 0.114 2.90mm
- Reference Standard
- UL
- Contact Resistance
- 20mOhm
- Mil Conformance
- NO
- Orientation
- Straight
- Style
- Board to Cable/Wire
- Kurşunsuz Kodu
- yes
