Adet bazlı fiyat
- 1+ adet$1.35
- 10+ adet$1.27
- 100+ adet$1.20
- 500+ adet$1.13
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Polarization Key
- POLARIZED HOUSING
- Özellikler
- Feed Through
- Row Spacing
- 0.100 (2.54mm)
- Contact Finish Mating
- NOT SPECIFIED
- Cable Termination
- IDC
- Min. Çalışma Sıcaklığı
- -55°C
- Test Voltage
- 1kV
- Gender
- Male
- Total Number Of Contacts
- 20
- Number Of Pcb Rows
- 2
- Sıra Sayısı
- 2
- Housing Material
- Polybutylene
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Fabrika Tedarik Süresi
- 4 Weeks
- Contact Pattern
- RECTANGULAR
- Renk
- Grey
- Contact Materials
- Nickel, Tin
- Pitch
- 2.54mm
- Yükseklik
- 5.5mm
- Akım Değeri
- 1A
- Genişlik
- 30.74mm
- Ambalaj
- Tray
- Boardside Pitch
- 0.100 2.54mm
- Montaj Tipi
- Through Hole
- Terminal
- Through Hole
- Hole Diameter
- 1 mm
- Reliability
- COMMERCIAL
- Pcb Contact Pattern
- RECTANGULAR
- Lead Pitch
- 2.54mm
- Flammability Rating
- UL94 V-0
- Montaj
- PCB, Through Hole
- Seri
- SEK
- Pozisyon Sayısı
- 20
- Parça Durumu
- Active
- Connector Type
- Ribbon Cable, DIP Header
- Insulation Resistance
- 10MOhm
- Max Current Rating
- 1A
- Pcb Thickness
- 127mm
- Number Of Conductors
- ONE
- RoHS Durumu
- ROHS3 Compliant
