Adet bazlı fiyat
- 1+ adet$0.56
- 10+ adet$0.53
- 100+ adet$0.50
- 500+ adet$0.47
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Pozisyon Sayısı
- 10
- Seri
- SEK
- Montaj
- PCB, Through Hole
- Flammability Rating
- UL94 V-0
- Lead Pitch
- 2.54mm
- Filter Feature
- NO
- Bodyshell Style
- RECEPTACLE
- Pcb Thickness
- 127mm
- Max Current Rating
- 1A
- Insulation Resistance
- 10MOhm
- Connector Type
- Ribbon Cable, DIP Header
- Parça Durumu
- Active
- Depth
- 6.1mm
- RoHS Durumu
- ROHS3 Compliant
- Number Of Conductors
- ONE
- Additional Feature
- LOW PROFILE
- Uzunluk
- 18mm
- Reach Svhc
- No SVHC
- Number Of Positions Loaded
- All
- Lead Length
- 3.3mm
- Reference Standard
- UL
- Contact Resistance
- 15mOhm
- Mil Conformance
- NO
- Orientation
- Straight
- Mixed Contacts
- NO
- Maks. Çalışma Sıcaklığı
- 105°C
- Material
- PBT, Resin, Thermoplastic
- Rated Current Signal
- 2A
- Contact Style
- IDC
- Özellikler
- Feed Through
- Polarization Key
- POLARIZED HOUSING
- Cable Termination
- IDC
- Min. Çalışma Sıcaklığı
- -55°C
- Contact Finish Mating
- NOT SPECIFIED
- Row Spacing
- 0.100 (2.54mm)
- Number Of Pcb Rows
- 2
- Total Number Of Contacts
- 10
- Gender
- Male
- Test Voltage
- 1kV
- Option
- GENERAL PURPOSE
