Adet bazlı fiyat
- 1+ adet$17.50
- 10+ adet$16.51
- 100+ adet$15.57
- 500+ adet$14.69
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Fabrika Tedarik Süresi
- 4 Weeks
- Kurşunsuz Kodu
- yes
- Parça Durumu
- Active
- Size
- 16B
- Mil Conformance
- NO
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Pozisyon Sayısı
- 72+Ground
- Akım Değeri
- 10A
- Sıra Sayısı
- 6
- Body Breadth
- 1.339 inch
- Working Voltage
- 250V
- Mixed Contacts
- YES
- Voltage Rated Ac
- 250V
- Insulation Resistance
- 10GOhm
- Contact Type
- Han® D
- Reliability
- COMMERCIAL
- Test Current
- 10A
- Montaj Tipi
- CABLE
- Additional Feature
- ROHS COMPLIANT
- Dielectric Withstanding Voltage
- 4000VAC V
- Orientation
- Straight
- Reach Svhc
- No SVHC
- Housing Material
- Polycarbonate (PC)
- Uzunluk
- 84.5mm
- ECCN Kodu
- EAR99
- Voltage Rated Dc
- 250V
- Durability
- 500 Cycles
- Wire Gauge Min
- 26 AWG
- Bodyshell Style
- PLUG
- Seri
- Han® DD
- Test Voltage
- 2kV
- Total Number Of Contacts
- 72
- Ambalaj
- Bulk
- Option
- GENERAL PURPOSE
- Flammability Rating
- UL94 V-0
- Iec Conformance
- NO
- Reference Standard
- UL, CSA
- Connector Type
- Insert without Contacts
- Wire Gauge Max
- 14 AWG
- Material Flammability Rating
- UL94 V-0
