Adet bazlı fiyat
- 1+ adet$17.50
- 10+ adet$16.51
- 100+ adet$15.57
- 500+ adet$14.69
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Din Conformance
- NO
- RoHS Durumu
- ROHS3 Compliant
- Ratings
- IP65
- Mounting Option1
- M3
- Contact Finish Mating
- NOT SPECIFIED
- Number Of Conductors
- ONE
- Contact Plating
- Silver
- Contact Resistance
- 3MOhm
- Material Flammability Rating
- UL94 V-0
- Wire Gauge Max
- 14 AWG
- Depth
- 33.6mm
- Contact Materials
- Copper
- Connector Type
- Insert without Contacts
- Çalışma Sıcaklığı
- -40°C~125°C
- Max Current Rating
- 10A
- Renk
- Gray
- Pin Sayısı
- 72
- Gender
- Male
- Mounting Option2
- LOCKING
- Terminal Stili
- Crimp
- Voltage Rated Dc
- 250V
- Uzunluk
- 84.5mm
- ECCN Kodu
- EAR99
- Housing Material
- Polycarbonate (PC)
- Reach Svhc
- No SVHC
- Orientation
- Straight
- Dielectric Withstanding Voltage
- 4000VAC V
- Reference Standard
- UL, CSA
- Option
- GENERAL PURPOSE
- Ambalaj
- Bulk
- Total Number Of Contacts
- 72
- Iec Conformance
- NO
- Flammability Rating
- UL94 V-0
- Bodyshell Style
- RECEPTACLE
- Test Voltage
- 2kV
- Seri
- Han® DD
- Durability
- 500 Cycles
- Wire Gauge Min
- 26 AWG
- Montaj Tipi
- CABLE
- Test Current
- 10A
