Adet bazlı fiyat
- 1+ adet$13.77
- 10+ adet$12.99
- 100+ adet$12.26
- 500+ adet$11.56
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Durability
- 50 Cycles
- RoHS Durumu
- ROHS3 Compliant
- Pozisyon Sayısı
- 48
- Contact Resistance
- 15mOhm
- Pitch
- 0.200 5.08mm
- Length Tail
- 9.5mm
- Ambalaj
- Bulk
- Reliability
- COMMERCIAL
- Mating Contact Row Spacing
- 0.2 inch
- Din Conformance
- YES
- Contact Finish
- Gold
- Contact Design
- PREASSEM CONN
- Total Number Of Contacts
- 48
- Uzunluk
- 14.7mm
- Rated Current Signal
- 6A
- Genişlik
- 94.8mm
- Mixed Contacts
- NO
- Material Flammability Rating
- UL94 V-0
- Body Depth
- 0.791 inch
- Iec Conformance
- NO
- Kurşunsuz Kodu
- yes
- Option
- GENERAL PURPOSE
- Number Of Positions Loaded
- All
- Montaj
- Panel
- Connector Type
- Receptacle, Female Sockets
- Sıra Sayısı
- 3
- Cable Types
- WIRE, DISCRETE
- Dielectric Withstanding Voltage
- 1550VAC V
- Empty Shell
- NO
- Parça Durumu
- Active
- Name Of Rows Loaded
- D,B,Z
- Montaj Tipi
- Panel Mount
- Style
- F
- Seri
- DIN 41612
- Terminal
- Solder Cup
- Ul Flammability Code
- 94V-0
- ECCN Kodu
- EAR99
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Yükseklik
- 29.05mm
- Material Insulation
- Thermoplastic, Glass Filled
