Adet bazlı fiyat
- 1+ adet$11.11
- 10+ adet$10.48
- 100+ adet$9.89
- 500+ adet$9.33
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Orientation
- Straight
- Name Of Rows Loaded
- Z,D
- Parça Durumu
- Active
- Housing Material
- Thermoplastic
- Dielectric Withstanding Voltage
- 1550VAC V
- Pcb Contact Pattern
- RECTANGULAR
- Max Current Rating
- 6A
- Ul Flammability Code
- 94V-0
- Terminal
- Press-Fit
- Style
- F
- Seri
- DIN 41612
- Montaj Tipi
- Through Hole
- Fabrika Tedarik Süresi
- 4 Weeks
- Insulation Resistance
- 1000000000000Ohm
- Reference Standard
- VDE,CSA
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- ECCN Kodu
- EAR99
- Material Insulation
- Polybutylene Terephthalate (PBT), Glass Filled
- Polarization Key
- POLARIZED HOUSING
- Mil Conformance
- NO
- Level Class
- 2
- Çalışma Sıcaklığı
- -40°C~105°C
- Insertion Forcemax
- 1.5568 N
- Depth
- 14.8mm
- Withdrawl Forcemin
- 1.5568 N
- Filter Feature
- NO
- Number Of Pcb Rows
- 3
- JESD-609 Kodu
- e4
- Gender
- Female
- Akım Değeri
- 6A
- Ambalaj
- Bulk
- Pitch
- 0.150 3.81mm
- Contact Resistance
- 15mOhm
- Pozisyon Sayısı
- 48
- RoHS Durumu
- ROHS3 Compliant
- Durability
- 400 Cycles
- Contact Finish
- Gold-Palladium
- Reliability
- COMMERCIAL
- Mating Contact Row Spacing
- 0.15 inch
- Din Conformance
- YES
