Adet bazlı fiyat
- 1+ adet$10.90
- 10+ adet$10.28
- 100+ adet$9.70
- 500+ adet$9.15
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Polarization Key
- POLARIZED HOUSING
- Mil Conformance
- NO
- Level Class
- 2
- Insertion Forcemax
- 1.5568 N
- Depth
- 14.7mm
- Withdrawl Forcemin
- 1.5568 N
- Filter Feature
- NO
- Contact Materials
- Gold, Nickel
- Number Of Pcb Rows
- 3
- JESD-609 Kodu
- e4
- Akım Değeri
- 6A
- Gender
- Female
- Fabrika Tedarik Süresi
- 4 Weeks
- Insulation Resistance
- 1000000000000Ohm
- Flammability Rating
- UL94 V-0
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- ECCN Kodu
- EAR99
- Material Insulation
- Thermoplastic, Glass Filled
- Reference Standard
- VDE,CSA
- Ul Flammability Code
- 94V-0
- Style
- F
- Reach Svhc
- No SVHC
- Seri
- DIN 41612
- Terminal
- Solder
- Montaj Tipi
- Through Hole
- Pcb Contact Row Spacing
- 5.08 mm
- Orientation
- Straight
- Name Of Rows Loaded
- Z,D
- Housing Material
- Thermoplastic
- Parça Durumu
- Active
- Max Current Rating
- 6A
- Dielectric Withstanding Voltage
- 1550VAC V
- Pcb Contact Pattern
- RECTANGULAR
- Empty Shell
- NO
- Connector Type
- Receptacle, Female Sockets
- Sıra Sayısı
- 3
- Montaj
- Through Hole
- Number Of Positions Loaded
- 32
- Iec Conformance
- NO
- Kurşunsuz Kodu
- yes
