09062326832

Teknik Özellikler

Iec Conformance

NO

Kurşunsuz Kodu

yes

Option

GENERAL PURPOSE

Number Of Pcb Rows

3

Filter Feature

NO

Number Of Positions Loaded

32

JESD-609 Kodu

e4

Montaj

Through Hole

Withdrawl Forcemin

1.5568 N

Insertion Forcemax

1.5568 N

Çalışma Sıcaklığı

-40°C~105°C

Level Class

2

Mil Conformance

NO

Connector Type

Receptacle, Female Sockets

Polarization Key

POLARIZED HOUSING

Sıra Sayısı

3

Total Number Of Contacts

32

Nem Hassasiyeti (MSL)

1 (Unlimited)

Material Insulation

Thermoplastic, Glass Filled

Rated Current Signal

6A

Reference Standard

VDE,CSA

Mixed Contacts

NO

Flammability Rating

UL94 V-0

Material Flammability Rating

UL94 V-0

Fabrika Tedarik Süresi

7 Weeks

Insulation Resistance

1000000000000Ohm

Reliability

COMMERCIAL

Kurşunsuz

Lead Free

Din Conformance

YES

Mating Contact Row Spacing

0.15 inch

Montaj Tipi

Through Hole

Style

F

Seri

DIN 41612

Contact Finish Mating

GOLD OVER NICKEL

Terminal

Press-Fit

Ul Flammability Code

94V-0

Pcb Contact Pattern

RECTANGULAR

Durability

400 Cycles

Dielectric Withstanding Voltage

1550VAC V

RoHS Durumu

ROHS3 Compliant
