Adet bazlı fiyat
- 1+ adet$14.67
- 10+ adet$13.84
- 100+ adet$13.06
- 500+ adet$12.32
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- ECCN Kodu
- EAR99
- Material Insulation
- Polybutylene Terephthalate (PBT), Glass Filled
- Reference Standard
- UL, CSA
- Lead Pitch
- 5.08mm
- Flammability Rating
- UL94 V-0
- Fabrika Tedarik Süresi
- 4 Weeks
- Insulation Resistance
- 1000000000000Ohm
- Akım Değeri
- 2A
- Gender
- Receptacle
- Contact Materials
- Copper
- Filter Feature
- NO
- Number Of Pcb Rows
- 3
- JESD-609 Kodu
- e4
- Mil Conformance
- NO
- Polarization Key
- POLARIZED HOUSING
- Level Class
- 2
- Çalışma Sıcaklığı
- -55°C~125°C
- Depth
- 30.92mm
- Working Voltage
- 250V
- Dielectric Withstanding Voltage
- 1550VAC V
- Pcb Contact Pattern
- RECTANGULAR
- Nominal Gerilim
- 500V
- Housing Material
- Thermoplastic
- Parça Durumu
- Active
- Name Of Rows Loaded
- Z,B,D
- Orientation
- Straight
- Montaj Tipi
- Panel Mount, Through Hole
- Style
- MH
- Reach Svhc
- No SVHC
- Seri
- DIN 41612
- Terminal
- Solder, Quick Connect
- Number Of Contacts
- 31
- Ul Flammability Code
- 94V-0
- Uzunluk
- 14.7mm
- Voltage Rated Dc
- 250V
- Rated Current Signal
- 6A
- Mixed Contacts
- YES
- Material Flammability Rating
- UL94 V-0
- Iec Conformance
- NO
