09062316821

Teknik Özellikler

Filter Feature

NO

Contact Materials

Copper

Number Of Pcb Rows

3

JESD-609 Kodu

e4

Akım Değeri

6A

Gender

Receptacle

Polarization Key

POLARIZED HOUSING

Mil Conformance

NO

Level Class

2

Çalışma Sıcaklığı

-55°C~125°C

Working Voltage

125V

ECCN Kodu

EAR99

Nem Hassasiyeti (MSL)

1 (Unlimited)

Material Insulation

Polybutylene Terephthalate (PBT), Glass Filled

Lead Length

22mm

Reference Standard

UL, CSA

Fabrika Tedarik Süresi

4 Weeks

Insulation Resistance

1000000000000Ohm

Lead Pitch

5.08mm

Flammability Rating

UL94 V-0

Montaj Tipi

Panel Mount, Through Hole

Ul Flammability Code

94V-0

Hole Diameter

1 mm

Style

MH

Reach Svhc

No SVHC

Seri

DIN 41612

Number Of Contacts

31

Terminal

Wire Wrap

Housing Material

Thermoplastic

Parça Durumu

Active

Pcb Contact Pattern

RECTANGULAR

Dielectric Withstanding Voltage

1550VAC V

Orientation

Straight

Name Of Rows Loaded

Z,B,D

Number Of Positions Loaded

All

Iec Conformance

NO

Kurşunsuz Kodu

yes

Option

GENERAL PURPOSE

Connector Type

Receptacle, Female Sockets and Blade Sockets

Sıra Sayısı

3
