Adet bazlı fiyat
- 1+ adet$18.50
- 10+ adet$17.45
- 100+ adet$16.46
- 500+ adet$15.53
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Çalışma Sıcaklığı
- -55°C~125°C
- Level Class
- 1
- Mil Conformance
- NO
- Connector Type
- Receptacle, Female Sockets
- Polarization Key
- POLARIZED HOUSING
- Sıra Sayısı
- 3
- JESD-609 Kodu
- e4
- Number Of Pcb Rows
- 3
- Contact Materials
- NOT SPECIFIED
- Filter Feature
- NO
- Number Of Positions Loaded
- All
- Iec Conformance
- NO
- Option
- GENERAL PURPOSE
- Gender
- Female
- Kurşunsuz Kodu
- yes
- Current Rating Amps
- 6A 15A
- Fabrika Tedarik Süresi
- 7 Weeks
- Material Flammability Rating
- UL94 V-0
- Material Insulation
- Polybutylene Terephthalate (PBT), Glass Filled
- ECCN Kodu
- EAR99
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Reference Standard
- UL, CSA
- Mixed Contacts
- YES
- Total Number Of Contacts
- 31
- Ul Flammability Code
- 94V-0
- Contact Finish
- Gold
- Seri
- DIN 41612
- Style
- MH
- Terminal
- Quick Connect, Wire Wrap
- Contact Arrangement
- S24P7
- Din Conformance
- YES
- Reliability
- COMMERCIAL
- Length Termination
- 0.866 inch
- Pcb Contact Row Spacing
- 5.08 mm
- Montaj Tipi
- Through Hole
- Orientation
- Straight
- Pitch
- 0.200 5.08mm
- Ambalaj
- Bulk
- Name Of Rows Loaded
- Z,B,D
- Pozisyon Sayısı
- 31 (24 + 7 Power)
