Adet bazlı fiyat
- 1+ adet$6.79
- 10+ adet$6.40
- 100+ adet$6.04
- 500+ adet$5.70
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Filter Feature
- NO
- Contact Materials
- NOT SPECIFIED
- Number Of Pcb Rows
- 2
- JESD-609 Kodu
- e4
- Gender
- Female
- Akım Değeri
- 15A
- Mil Conformance
- NO
- Depth
- 14.7mm
- Reference Standard
- VDE,CSA
- ECCN Kodu
- EAR99
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Material Insulation
- Thermoplastic, Glass Filled
- Fabrika Tedarik Süresi
- 4 Weeks
- HTS Kodu
- 8536.69.40.40
- Insulation Resistance
- 1000000000000Ohm
- Body Breadth
- 0.583 inch
- Flammability Rating
- UL94 V-0
- Montaj Tipi
- Through Hole
- Pcb Contact Row Spacing
- 10.16 mm
- Ul Flammability Code
- 94V-0
- Terminal
- Solder
- Style
- H 15
- Seri
- DIN 41612
- Contact Finish Mating
- SILVER
- Parça Durumu
- Active
- Housing Material
- Thermoplastic
- Pcb Contact Pattern
- STAGGERED
- Dielectric Withstanding Voltage
- 3100VAC V
- Max Current Rating
- 15A
- Orientation
- Straight
- Name Of Rows Loaded
- Z,D
- Number Of Positions Loaded
- All
- Kurşunsuz Kodu
- yes
- Option
- GENERAL PURPOSE
- Iec Conformance
- NO
- Sıra Sayısı
- 2
- Connector Type
- Receptacle, Female Blade Sockets
- Montaj
- Through Hole
- Mixed Contacts
- NO
- Uzunluk
- 94.75mm
