09061482901

Teknik Özellikler

Fabrika Tedarik Süresi

4 Weeks

Flammability Rating

UL94 V-0

Reference Standard

VDE,CSA

Material Insulation

Thermoplastic, Glass Filled

Nem Hassasiyeti (MSL)

1 (Unlimited)

Depth

22mm

Level Class

1

Mil Conformance

NO

Polarization Key

POLARIZED HOUSING

JESD-609 Kodu

e3

Number Of Pcb Rows

3

Filter Feature

NO

Gender

Male

Akım Değeri

6A

Orientation

Right Angle

Name Of Rows Loaded

Z,B,D

Parça Durumu

Active

Housing Material

Thermoplastic

Nominal Gerilim

125V

Empty Shell

NO

Pcb Contact Pattern

RECTANGULAR

Max Current Rating

6A

Ul Flammability Code

94V-0

Terminal

Solder

Number Of Contacts

48

Seri

DIN 41612

Style

F

Pcb Contact Row Spacing

2.54 mm

Montaj Tipi

Through Hole, Right Angle

Material Flammability Rating

UL94 V-0

Mixed Contacts

NO

Rated Current Signal

6A

Uzunluk

93.9mm

Sıra Sayısı

3

Connector Type

Header, Male Pins

Montaj

Through Hole

Number Of Positions Loaded

All

Option

GENERAL PURPOSE

Kurşunsuz Kodu

yes

Iec Conformance

NO
