09060152922

Teknik Özellikler

Terminal

Quick Connect - 0.250 (6.3mm)

Material Flammability Rating

UL94 V-0

Name Of Rows Loaded

Z,D

Reference Standard

VDE,CSA

Sıra Sayısı

2

Ambalaj

Bulk

Body Depth

0.988 inch

Body Breadth

0.583 inch

Kurşunsuz

Lead Free

Connector Type

Header, Male Blades

Length Termination

0.118 inch

Dielectric Withstanding Voltage

3100VAC V

Akım Değeri

15A

Flammability Rating

UL94 V-0

Contact Resistance

8mOhm

ECCN Kodu

EAR99

Din Conformance

YES

Iec Conformance

NO

RoHS Durumu

ROHS3 Compliant

Ul Flammability Code

94V-0

Operating Temperature Min

-65°C

Contact Plating

Silver

Pozisyon Sayısı

15 (13 Power + 2 Leading Contacts)

Nem Hassasiyeti (MSL)

1 (Unlimited)

Number Of Pcb Rows

2

Kurşunsuz Kodu

yes

Montaj

Panel

Option

GENERAL PURPOSE

Number Of Contacts

15

Number Of Positions Loaded

All

Insulation Resistance

1000000000000Ohm

Reliability

COMMERCIAL

Contact Finish Mating

NOT SPECIFIED

Polarization Key

POLARIZED HOUSING

Seri

DIN 41612

Reach Svhc

No SVHC

Fabrika Tedarik Süresi

14 Weeks

Body Length Or Diameter

3.701 inch

Style

H 15

Mil Conformance

NO
